Description

field of use
School canteen、Enterprise canteen、Central Kitchen

Technical Parameters
Heat source type: natural gas 10T/12T 2000±500pa liquefied gas 19Y/20Y/22Y 2800±500pa

Gas consumption: rated 6.3m³/h, average 5m³/h (natural gas)

Heat load: rated 65kW, average 45kW

Input voltage: 220VAC

Rated power: 1kW (average 0.5KW)

Maximum cooking volume: 30kg

Cooking time: 8min/times

Inner diameter of pot mouth: 390mm

The maximum diameter of the pot: 600mm

Pot inner depth: 598mm

Appearance material: 304 stainless steel

Electric control panel: intelligent system

Screen: 10 inch touch screen

Air inlet: G1 external thread

Water inlet: G½ external thread

Input water pressure: 0.1~0.36mpa

Product net weight: 360kg

Product size: width 1350×depth 1250×height 1450(mm)

Packing size: width 1400×depth 1300×height 1560(mm)

Including method: log frame
